Lichuan Integrated Servo Motors Driver – L‑Shaped Design

Product Description

This Integrated Servo Motors Driver integrates motor, driver, encoder, and control electronics into a single L‑shaped housing. Compared with traditional separated motor and driver solutions, the Lichuan Integrated Servo Motors Driver significantly reduces wiring complexity, installation time, and electromagnetic interference. With a rated speed of 3000RPM, it delivers fast response, stable torque, and precise control for continuous industrial operation.

Product Introduction

The Lichuan Integrated Servo Motors Driver features an innovative L‑shaped integrated design that combines the servo motor and servo driver into one compact unit. With power options of 200W / 400W / 600W, torque ranges from 0.637N.m to 1.91N.m, and support for DC24V / DC48V power supplies, this Integrated Servo Motors Driver is engineered for high‑precision, high‑reliability industrial automation applications. The IP65 protection level ensures stable operation in harsh environments, making it ideal for smart manufacturing and modern motion control systems.

Product Information

The Lichuan Integrated Servo Motors Driver is designed to simplify system architecture while delivering excellent dynamic response and positioning accuracy. The L‑shaped structure optimizes space utilization, reduces cabinet depth, and improves heat dissipation. This Integrated Servo Motors Driver supports high current output up to 15A, enabling strong torque performance and smooth motion control under demanding load conditions.

Technical Parameters Table

All parameters of the Integrated Servo Motors Driver support OEM and customization.

Basic Information

• Brand: Lichuan

• Product Name: Integrated Servo Motors Driver

• Structure Type: L‑Shaped Integrated Design

• Power Options: 200W / 400W / 600W

• Rated Speed: 3000RPM

• Protection Level: IP65

• Application: Industrial Automation and Motion Control

Application Fields

• Industrial automation equipment

• CNC machines and machining centers

• Packaging and printing machinery

• Robotics and automated assembly lines

• Semiconductor and electronics manufacturing

The Integrated Servo Motors Driver is suitable for applications requiring compact structure and high precision.

Specifications

• Rated Voltage: DC24V / DC48V

• Rated Power: 200W / 400W / 600W

• Rated Torque: 0.637N.m / 1.27N.m / 1.91N.m

• Rated Current: 6.0A / 10A / 12A / 15A

• Rated Speed: 3000RPM

• Encoder Type: High‑resolution incremental / absolute encoder (optional)

• Control Modes: Position / Speed / Torque

• Protection Class: IP65

The specifications of the Integrated Servo Motors Driver can be customized according to different application requirements.

Product Selling Points

• L‑shaped Integrated Servo Motors Driver saves installation space

• All‑in‑one structure reduces wiring and cabinet cost

• High torque density with fast dynamic response

• IP65 protection for dust‑proof and water‑resistant operation

• Stable performance at high speed up to 3000RPM

Product Features

• Compact L‑shaped integrated structure

• High‑current output up to 15A

• Advanced digital servo control algorithm

• Intelligent protection: over‑voltage, over‑current, over‑temperature

• Low noise, low vibration, and high efficiency

Every feature of the Lichuan Integrated Servo Motors Driver is optimized for long‑term industrial use.

Product Technology

The Integrated Servo Motors Driver adopts advanced vector control and closed‑loop servo algorithms. High‑speed processors manage current, speed, and position loops in real time, ensuring precise control accuracy and excellent dynamic performance even under sudden load changes.

Working Principle

The Lichuan Integrated Servo Motors Driver receives control commands from a PLC, CNC controller, or motion control system. Encoder feedback continuously monitors motor position and speed, while the built‑in driver adjusts output current in real time to achieve accurate position, speed, or torque control within a closed‑loop system.

Product Applications

• Linear modules and actuators

• Indexing tables and rotary platforms

• Automated conveying systems

• Pick‑and‑place and positioning systems

Product Advantages

• Integrated Servo Motors Driver reduces system size and wiring

• L‑shaped design improves space utilization and heat dissipation

• High reliability for continuous industrial operation

• Simplified installation and maintenance

• Flexible voltage and power configuration

Product Services

• Pre‑sales technical consultation for Integrated Servo Motors Driver selection

• OEM / ODM customization service

• Complete manuals, drawings, and parameter tables

• Stable mass production and fast delivery

Production Process

The Lichuan Integrated Servo Motors Driver is produced through precision machining, automated assembly, multi‑stage functional testing, and aging tests to ensure consistent quality and performance.

Operation Method

1. Mount the Integrated Servo Motors Driver securely.

2. Connect DC power and control signals according to the wiring diagram.

3. Set parameters via software or controller.

4. Perform test operation and fine‑tuning before full load use.

Precautions

• Confirm correct voltage before powering on the Integrated Servo Motors Driver.

• Ensure adequate cooling and ventilation.

• Avoid operation beyond rated current and torque.

• Follow all safety and installation guidelines.

Product Certifications

• CE Certification

• RoHS Compliance

• ISO9001 Quality Management System

All Lichuan Integrated Servo Motors Driver products comply with international standards.

Quality Assurance

Each Integrated Servo Motors Driver undergoes comprehensive inspection and testing before shipment. We ensure stable performance, high reliability, and long service life.

Customer Service Information

• Professional technical support

• Detailed documentation and application guidance

• Fast after‑sales response

• Long‑term cooperation and global service support

The Lichuan Integrated Servo Motors Driver delivers compact design, precise control, and dependable service for modern automation systems.

Company Introduction

Lichuan is a professional manufacturer specializing in motion control solutions, including the Integrated Servo Motors Driver series. With advanced R&D capability, strict quality management, and global market experience, Lichuan provides reliable automation products for customers worldwide.

FAQ

Q1: What is the advantage of the L‑shaped Integrated Servo Motors Driver?
A: The L‑shaped design saves space, improves heat dissipation, and simplifies cabinet layout.

Q2: Does this Integrated Servo Motors Driver support DC24V and DC48V?
A: Yes, both DC24V and DC48V versions are available.

Q3: Can the encoder and communication be customized?
A: Yes, encoder type and communication interfaces can be customized for OEM projects.
